- Motor Control /
- Motor Starter /
- Cutler Hammer /
AN14SN0Y3E300
AN14SN0Y3E300
IMAGES ARE FOR REFERENCE ONLY.
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
AN14SN0Y3E300 Specifications
View Full SpecificationsView Specifications
AN14SN0Y3E300, Cutler Hammer, Freedom Series, type AN14, 3P, 3PH, 270A, 600V, 75hp @ 208V, 100hp @ 240V, 200hp @ 480V, 200hp @ 600V, 150hp @ 380V 50Hz, complete with 48V 50Hz, FLA range 60-300A, service-limit current rating 311A, standard C396 OLR, SEL reset, SEL class, non-reversing, full voltage, manual or selectable reset electronic overload relay starters, NEMA size 5, suitable for use with Freedom Series motor control systems
| Manufacturer | Cutler Hammer | Subcategory | Motor Starter |
| Family | Freedom Series | Amperage | 270 |
| Poles | 3 | Phase | 3 |
| Manufacturer | Cutler Hammer | ||
| Subcategory | Motor Starter | ||
| Family | Freedom Series | ||
| Amperage | 270 | ||
| Poles | 3 | ||
| Phase | 3 |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
