AN54DN0L3EP05
AN54DN0L3EP05
IMAGES ARE FOR REFERENCE ONLY.
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
AN54DN0L3EP05 Specifications
View Full SpecificationsView Specifications
AN54DN0L3EP05, Cutler Hammer, Freedom Series, type AN54, 3P, 1 or 3PH, 27A, 600V, 2hp @ 115V 1PH, 3hp @ 230V 1PH, 7.5hp @ 208V 3PH, 7.5hp @ 240V 3PH, 10hp @ 480V 3PH, 10hp @ 600V 3PH, 10hp @ 380V 50Hz, complete with 380V-415V 50Hz, FLA range 0.1-0.5A, service-limit current rating 32A, standard C396 OLR, SEL reset, SEL class, reversing, full voltage, manual or selectable reset electronic overload relay starters, NEMA size 00, suitable for use with Freedom Series motor control systems
| Manufacturer | Cutler Hammer | Subcategory | Motor Starter |
| Family | Freedom Series | Amperage | 27 |
| Poles | 3 | Phase | 3 |
| Manufacturer | Cutler Hammer | ||
| Subcategory | Motor Starter | ||
| Family | Freedom Series | ||
| Amperage | 27 | ||
| Poles | 3 | ||
| Phase | 3 |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
