CE15MN2A
CE15MN2A
IMAGES ARE FOR REFERENCE ONLY.
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
CE15MN2A Specifications
View Full SpecificationsView Specifications
CE15MN2A, Cutler Hammer, Freedom Series, type CE15MN, 2P, 1 or 3PH, 105A, 600V, max UL hp: 10hp @ 115V 1PH, 10hp @ 230V 1PH, 30hp @ 200V 3PH, 40hp @ 230V 3PH, 75hp @ 460V 3PH, 100hp @ 575V 3PH; max kW rating: 30hp @ 220V 3PH, 55hp @ 380V 3PH, 55hp @ 415/440V 3PH, 75hp @ 500/550V 3PH, 45hp @ 660V 3PH, complete with 110V 50Hz or 120V 60Hz, max UL AC-3 ampere rating AC 105A, IEC 947 AC-1 thermal current 135A, AC coil, non-reversing, open type contactors, IEC size M, suitable for use with Freedom Series motor control systems
| Manufacturer | Cutler Hammer | Subcategory | Contactor |
| Family | Freedom Series | Amperage | 105 |
| Poles | 2 | Voltage | 600 |
| Manufacturer | Cutler Hammer | ||
| Subcategory | Contactor | ||
| Family | Freedom Series | ||
| Amperage | 105 | ||
| Poles | 2 | ||
| Voltage | 600 |
Electrical.com is NOT an authorized distributor for Cutler Hammer and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
The Cutler Hammer CE15MN2A is a heavy-duty contactor from the Cutler Hammer Freedom Series series, engineered for performance in commercial and industrial motor control applications. The CE15MN2A is rated for 105A, supports a coil voltage range of 110-120V, supports 3-phase operation, configured as a 2-poles unit.
This contactor offers durable operation in demanding environments, designed to manage frequent motor starts, resist arcing, and maintain contact reliability over long service intervals. The A200 series is compatible with Eaton overload relays and control accessories, making it a trusted solution in control panels and starter assemblies.
You can find the CE15MN2A at Electrical.com, your reliable partner for Eaton and Cutler Hammer contactors, motor starters and industrial control products. Our dedicated sales team is ready to assist with technical questions, product selection, and support.
