E511E16X3N Cutler Hammer IT Electro-Mechanical Line 160A Contactor

E511E16X3N

Cutler Hammer - Contactor

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

What's the difference?View Specifications

E511E16X3N Specifications

View Full SpecificationsView Specifications

E511E16X3N, Cutler Hammer, IT Electro-Mechanical Line, type E511, IEC, DC-operated full voltage reversing contactor, E-frame, 3P, 3PH, 160A, 600V, 15HP @ 115/120V, 30HP @ 220/230V, 50HP @ 200/208V, 60HP @ 230/240V, 75HP @ 380/415V, 125HP @ 460/480V, 125HP @ 575/600V, complete with 24V DC coil, suitable for use with IT IEC Electro-Mechanical motor control systems

Manufacturer	Cutler Hammer	Subcategory	Contactor
Family	IT Electro-Mechanical Line	Amperage	160
Poles	3	Voltage	600
Manufacturer	Cutler Hammer
Subcategory	Contactor
Family	IT Electro-Mechanical Line
Amperage	160
Poles	3
Voltage	600

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

E511E16X3N Specifications:

Part NumberE511E16X3N

Manufacturers

Cutler Hammer

Sub-CategoryContactor

FamilyIT Electro-Mechanical Line

TypeE511

Weight6 lbs

Amperage160

Poles3

Voltage600

Phase3
