N101BSAC3A Cutler Hammer Motor Starter Motor Control

N101BSAC3A

Cutler Hammer - Motor Starter

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

What's the difference?View Specifications

N101BSAC3A Specifications

View Full SpecificationsView Specifications

N101BSAC3A, Cutler Hammer, IT Electro-Mechanical Line, type N101, 3P, 3PH, 9A, 600V, 1.5hp @ 200-208V 60Hz, 1.5hp @ 230-240V 60Hz, 2hp @ 460-480V 60Hz, 2hp @ 575-600V 60Hz, 1.5hp @380V 50Hz, complete with 24VDC, overload adjustment range 1.4A-4.4A, DC coil, non-reversing, open type starters, NEMA size 00, suitable for use with Cutler Hammer motor control systems

Manufacturer	Cutler Hammer	Subcategory	Motor Starter
Family	IT Electro-Mechanical Line	Amperage	9
Poles	3	Phase	3
Manufacturer	Cutler Hammer
Subcategory	Motor Starter
Family	IT Electro-Mechanical Line
Amperage	9
Poles	3
Phase	3

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

N101BSAC3A Specifications:

Part NumberN101BSAC3A

Manufacturers

Cutler Hammer

Sub-CategoryMotor Starter

FamilyIT Electro-Mechanical Line

TypeN101

UPC782113910536

Weight10 lbs

Amperage9

Poles3

Phase3
