14JTM32AA
14JTM32AA
IMAGES ARE FOR REFERENCE ONLY.
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
14JTM32AA Specifications
View Full SpecificationsView Specifications
14JTM32AA, Siemens, Class 14, heavy duty motor starter, type 14JT, 3P, 3PH, 575V, 40 HP @ 200V, 50 HP @ 230V, 100 HP @ 460V, 100 HP @ 575V, complete with 220V-240V 60 Hz coil and 67-135A overload, NEMA size 4, suitable for use with class 14 motor control systems
| Manufacturer | Siemens | Subcategory | Motor Starter |
| Family | Class 14 | Amperage | 135 |
| Poles | 3 | Phase | 3 |
| Manufacturer | Siemens | ||
| Subcategory | Motor Starter | ||
| Family | Class 14 | ||
| Amperage | 135 | ||
| Poles | 3 | ||
| Phase | 3 |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
14JTM32AA Specifications:
Part Number14JTM32AA
Manufacturers
Sub-CategoryMotor Starter
Other Names14JTM-32AA
FamilyClass 14
Type14JT
Weight10 lbs
Amperage135
Poles3
Phase3
Voltage575
NEMA Rating4
Coil Voltage Min220
Coil Voltage Max240
