3TF6944-0CQ7
IMAGES ARE FOR REFERENCE ONLY.
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
3TF6944-0CQ7 Specifications
View Full SpecificationsView Specifications
3TF6944-0CQ7, Siemens, World Series, vacuum contactor, type 3TF, 3P, 3PH, 820A, 600V, complete with 380/415V 50Hz, 480V 60Hz AC coil, 4 N/O - 4 N/C auxiliary contact, AC magnetic contactor, suitable for use with 3TF series motor control systems
| Manufacturer | Siemens | Subcategory | Contactor |
| Family | World Series | Amperage | 820 |
| Poles | 3 | Voltage | 600 |
| Manufacturer | Siemens | ||
| Subcategory | Contactor | ||
| Family | World Series | ||
| Amperage | 820 | ||
| Poles | 3 | ||
| Voltage | 600 |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
3TF6944-0CQ7 Specifications:
Part Number3TF6944-0CQ7
Manufacturers
Sub-CategoryContactor
FamilyWorld Series
Type3TF
UPC754554398983
Weight30 lbs
Amperage820
Poles3
Voltage600
Phase3
Coil Voltage Min480
Coil Voltage Max480
