40BP12AC

Siemens Contactor 40BP12AC

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

View Specifications


40BP12AC Specifications

View Specifications

40BP12AC, Siemens, Class 40 non-reversing contactor, type 40BP, 2P, 1PH, 9A, 600V, 1/3HP @ 115V, 1HP @ 208/230V, complete with 220-240/440-480V AC 60Hz coil, open type, NEMA size 00, AC non-combination contactor, suitable for use with Class 40 series motor control systems

Manufacturer
Siemens
Subcategory
Contactor
Family
Class 40
Amperage
9
Poles
2
Voltage
600

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

Pearl Logo
Standard Warranty Logo
Ships WorldWide Logo
Rush Shipping Logo
40BP12AC Specifications:
Part Number40BP12AC
Manufacturers
Sub-CategoryContactor
FamilyClass 40
Type40BP
UPC783087564954
Weight2 lbs
Amperage9
Poles2
Voltage600
Phase1
Coil Voltage Max480
